Tailored to optimize and enhance your indoor environments

POD2 Airlab Winner Microsensor challenge 2021
Capteurs POD2

The cutting-edge indoor monitoring system

The POD2 is the ultimate all-in-one solution for understanding and controlling your indoor environment. Designed to manage and optimize your spaces, it ensures not only the health and well-being of occupants but also the effective functioning of various environments. The POD2 stands out with its connected, real-time monitoring, allowing for continuous and simultaneous observation of a wide range of sensory parameters. It accurately identifies and quantifies indoor nuisances and hazards by capturing real-time physical, chemical, and perceptual data (gases, odors, particles, etc.), providing a detailed view of your environment.

Fully customizable, the POD2 meets the specific needs of various environments, such as offices, shopping centers, public buildings, public restrooms, and other spaces requiring rigorous monitoring. When paired with the EllonaSoft platform, the POD2 can also generate real-time alerts and recommend appropriate remediation actions to address identified issues. Its exceptional flexibility and advanced features make the POD2 a versatile and essential solution for all environmental monitoring needs. Whether you are a business, a public institution, or a manager of commercial or residential spaces, the POD2 provides a reliable and effective solution for ensuring a healthy and optimized indoor environment.

POD2 configurations

Technical specifications and data types analyzed by the POD2:

Native features

temperature

Temperature

Humidité

Humidity

Pression atmosphérique

Atmospheric pressure

Lumière

Light

cov

Total VOCs

Vibrations

Vibrations

bruit

Noise

Optional sensors

Gaz

Gaz

Up to 4 electrochemical sensors and 1 optical sensor

particules

Particles

odeur

Odor

Quality / 1 board with 4 MOX sensors

Explore all the capabilities of the sensor

Discover the perfect synergy between our POD2 product and the EllonaSoft analysis platform.

Designed by Ellona, expert in environmental technology, this combination delivers the ultimate solution for intelligent and advanced emissions monitoring.

Learn more about EllonaSoft

Examples of sector-specific configurations

Hopitaux

Healthcare / Hospitals

Temperature / Humidity / Odors / Atmospheric Pressure / Noise / CO₂ / PM / EtO/ CH₂O / NH₃ / H₂S

Bureaux et infrastructures

Offices – Open Spaces

Temperature / Humidity / Odors / Atmospheric Pressure / Noise / CO₂ / PM

Centre commercial

Shopping Centers

Temperature / Humidity / Odors / Atmospheric Pressure / Noise / CO₂ / PM / NO₂

Zones industrielles

Industrial Workshops

Temperature / Humidity / Odors / Atmospheric Pressure / Noise / CO₂ / PM / NO₂ / CO / NO / H₂S

Secteur accueil , écoles

Airports – Terminals

Temperature / Humidity / Odors / Atmospheric Pressure / Noise / CO₂ / PM / NO₂ / O₃ / H₂S / NH₃

A product with numerous technical advantages

Digitization of Human Senses (HSD)
Unique combination of physical, chemical, and perceptual data

Signature of sources
Identify pollution sources and uncover root causes using our source fingerprinting method.

Odor recognition
Leverage extensive databases for precise identification and quantification of odors..

Patented technology
Benefit from our high-quality electronic technology, ensuring an excellent signal-to-noise ratio and optimal detection limit (LOD).

Real-time data
Benefit from continuous monitoring with data updates every 10 seconds.

Dynamic system
Independent air intake and exhaust channels enable accurate measurements of gases and particles.

Multiple connectivity options
Stay connected with our agnostic network supporting 2G/3G, Wi-Fi, LTE-M, Ethernet, and LoRa..

Multiple power options
PoE, Micro-USB, and backup battery

Remote updates
Perform software updates, configurations, and maintenance remotely without service interruption.

Triggering of remediation actions
Control processes through the APIs integrated with EllonaSoft for automatic remediation.

Multicolor LED notifications
Receive visual alerts with multicolor LED notifications.

IP network
Take advantage of device-to-device communication for maximum efficiency.

ADEME standard (French Agency for Environment and Energy Management)
Our devices comply with health standards set by the French Ministry of Ecological Transition and ADEME.

A one-of-a-kind approach for your operations

  • Features
  • Resources

Integrated sensors

Voir plus

Optional sensors :

SensorMeasuring RangeResolution LODTypical Accuracy
PM10 to 1 000 µg/m³1 µg/m³0,5 µg/m³±2 µg/m³
PM2.50 to 2 000 µg/m³1 µg/m³0,5 µg/m³±3 µg/m³
PM40 to 2 000 μg/m³1 μg/m³0,5 μg/m³±3 μg/m³
PM100 to 10 000 µg/m³1 µg/m³0,5 µg/m³±4 µg/m³
PM countPM0,5, PM1, PM2,5, PM10 particles/m³1 particleLinearity error <5%, Repeatability error <3%
SensorPrincipleELLONA virtual sensorTraining
Odour DetectionRelative odour event in Indoor environment (baseline monitoring)“ELLONA distance” Anomaly detection OIIL: Odour Intensity Index Level in real timeSampling? No Inputs? Ambiant exposition to event or QR code surveys
Odour IntensityOdour Quantification Event detection“IOU: Instrumental Odour Unit in real time”Sampling? No Inputs? Ambiant exposition to event or QR code surveys
Source IdentificationEvent Fingerprinting“Identification” Classifier & Trigger valueSampling? No Inputs? Ambiant exposition to event or QR code surveys
SensorSensor TypeMeasuring RangeLODResolution Interferences
AlcoholsElectrochemical0 to 200 ppm0.009 ppm0.001 ppm+1% CO, hydrocarbons
CH₂O (Formaldéhyde)Electrochemical0 to 10 ppm0.002 ppm0.001 ppm+3% H2 ; +15% CO ; +50% Ethanol, organic solvents
Cl₂Electrochemical0 to 20 ppm0.018 ppm0.006 ppm100% NO₂ ; -80% H₂S
COElectrochemical0 to 1,000 ppm0.063 ppm0.001 ppm+10% H₂ ; -2% NO₂
CO₂ – NDIROptical0 to 5,000 ppm± 30 ppm1 ppm
EtO (Ethylene Oxyde)Electrochemical0 to 10 ppm0.005 ppm0.001 ppm+30% H2 ; +50% CO; +60% EtOH
H₂Electrochemical0 to 2,000 ppm6 ppm2 ppmNO<40%; C2 H4<25%
H₂Electrochemical0 to 4,000 ppm6 ppm2 ppm+70% CO
H₂Electrochemical0 to 40,000 ppm15 ppm5 ppm+60% CO
HClElectrochemical0 to 20 ppm0.2 ppm0.06 ppm50% HBr, <200% H2S; -30% NO2; <25% Cl2
HCNElectrochemical0 to 100 ppm0.129 ppm0.043 ppm+300% H₂ ; -180% NO₂ ; -12% Cl₂ ; +10% SO₂
H₂O₂ (Peroxyde)Electrochemical0 to 100 ppm0.1 ppm0.03 ppm+ 100% SO₂
H₂SElectrochemical0 to 50 ppm0.003 ppm0.001 ppm-30% NO₂ ; -25% Cl₂ ; +10% SO₂
NH₃Electrochemical0 to 100 ppm0.09 ppm0.03 ppm-20% SO₂
NOElectrochemical0 to 250 ppm0.011 ppm0.001 ppm+10% H₂ S; +2% NO₂ ; + 3% SO₂
NO₂Electrochemical0 to 5 ppm0.003 ppm0.001 ppm+10% H₂S; +2% NO₂; + 3% SO₂
NO₂ + O₃Electrochemical0 to 10 ppm0.003 ppm0.001 ppm+100% Cl₂
O₂Electrochemical0 to 30%0.1%0.1%
PH₃Electrochemical0 to 10 ppm<0.1 ppm<15% H2S; <30% NO2; <60% SO2
RSH (Tertiobutyl Mercaptan)Electrochemical0 to 14 ppm0.1 ppm0.03 ppm
SO₂Electrochemical0 to 50 ppm0.008 ppm0.001 ppm130% NO₂ : -60% Cl₂ ; + 40% C₂H₄
Sensor TypeMeasuring RangeAccuracyResolution
Temperature-40°C to +85°C±1°C0.1°C
Humidity0 to 100% HR±3% HR0.01% HR
Atmospheric pressure300 to 1,100 hPa±0,6 hPa0.1 hPa
Total VOC0 to 1,000 ppm1 ppm0.1 ppm
Light color (t°)0 to 12,000 K50 K1 K
Light intensity0 to 10,000 Lux5 Lux1 Lux
Noise30 to 120 dBA1 dBA0.1 dBA
Vibration (level)0 to 40 m/s²0.01 m/s²0.005 m/s²
